ND 122385 ENGINE MOUNTING AMMANN

Introduction to the product

The ND 122385 Ammann Engine Mounting is a critical vibration-dampening component engineered to secure and stabilize the engine within Ammann construction machinery. As part of the Engine & Powertrain Components range, it plays a key role in reducing mechanical stress, noise, and vibration transmission between the engine block and the chassis frame. Designed with advanced elastomeric materials and steel bonding, ND122385 ensures optimal load distribution and engine alignment, extending the operational life of your Ammann equipment under harsh working conditions. At 3GEN Export, we provide OEM-grade engine mountings, tested to match the original Ammann specifications in strength, hardness, and geometry. Whether you are replacing a worn isolator or conducting preventive maintenance, this engine mounting guarantees smoother operation, reduced vibration fatigue, and improved machine stability across your construction fleet.

Technical Specifications

The following specifications are based on verified engineering data for Ammann engine mountings and include both metric and imperial conversions for global reference.

• Brand: Ammann
• Category: Engine & Powertrain Components
• Estimated Weight: 4.5 kg / 9.92 lbs
• Estimated Size (L × W × H): 18 × 14 × 10 cm | 7.09 × 5.51 × 3.94 in
• Material: High-strength rubber bonded with corrosion-protected steel
• Operating Temperature: −40°C to +120°C (−40°F to +248°F)
• Mounting Type: Threaded bolt-on base with vibration-isolation insert
• Shore Hardness: 65 ± 5 Shore A
• Torque Rating: 160 Nm (118 lb-ft)
• Quality Standard: OEM-equivalent, ISO/TS 16949 certified production

Dimensions and weight are estimated for standard assemblies. Always verify fitment and torque values per your Ammann service manual before installation.

Compatibility and Application

This Engine Mounting is compatible with various Ammann compactors, rollers, and pavers. It’s designed to isolate vibration generated by diesel engines, protecting both engine mounts and chassis components from excessive dynamic loads. Commonly used in models such as Ammann ARX and AV series, this part ensures reliable powertrain performance, especially under high-impact compaction or uneven terrain operations. Engine mountings like this are essential for maintaining machine stability, operator comfort, and extended drivetrain lifespan. If you are unsure whether this part matches your model, contact 3GEN Export with your machine serial number for a compatibility check.

Key Features and Advantages

• Superior vibration isolation: Reduces engine vibration transfer to the frame, minimizing structural fatigue.
• High load capacity: Supports engine mass effectively during dynamic operations.
• Temperature and oil resistant: Maintains elasticity even under exposure to fuel, oil, and temperature extremes.
• Precision-engineered design: Guarantees perfect fitment with factory mount locations.
• Durable construction: Rubber-metal bonding ensures long service life under high-frequency loads.
• Enhanced operator comfort: Reduces cabin vibration and noise levels.
• OEM alternative solution: Equivalent in quality and performance to Ammann original parts at a competitive cost.

Installation and Maintenance Guide

Preparation: Power off the machine and ensure it’s on a stable surface. Use hydraulic support to slightly lift the engine to relieve load on existing mounts. Check alignment between the engine and the chassis before removing old mountings. Installation: Replace one mounting at a time. Clean contact surfaces thoroughly and apply anti-seize compound to bolts if necessary. Align this Engine Mounting correctly and torque all bolts to 160 Nm (118 lb-ft) using a calibrated wrench. Verify that all washers and spacers are installed per Ammann guidelines. Maintenance: Inspect mountings every 500 operating hours for cracks, oil saturation, or compression set. Replace immediately if visible deterioration occurs. Keep the engine area clean and free of hydraulic leaks to preserve rubber elasticity.

Why Choose 3GEN Export

• OEM-quality assurance: All mountings are manufactured under strict QA systems and tested for dynamic load endurance.
• Worldwide delivery: Fast logistics ensures shipment to any location within 5 working days.
• Comprehensive warranty: Covered by a 1-year OEM warranty against manufacturing defects.
• Cost-effective supply: Competitive pricing with no compromise on quality or performance.
• Trusted global supplier: 3GEN Export serves construction, road-building, and compaction industries with consistent reliability.

Conclusion

This Ammann Engine Mounting is the ideal replacement component for maintaining vibration control and mechanical stability in Ammann machinery. Its robust construction, precise geometry, and tested performance make it a dependable OEM-grade solution. Order your Engine Mounting Ammann spare part from 3GEN Export today — OEM quality, global delivery in just 5 working days.

Technical Data Table



Specification	Value
Part Number	ND 122385
Brand	Ammann
Product Name	Engine Mounting
Weight	4.5 kg / 9.92 lbs
Size	18 × 14 × 10 cm / 7.09 × 5.51 × 3.94 in
Material	Steel bonded to high-resilience rubber compound
Category	Engine & Powertrain Components
Compatible Models	Ammann ARX, AV series rollers and compactors (confirm via model plate)
Torque Rating	160 Nm / 118 lb-ft
Warranty	1 Year OEM Warranty
Delivery Time	5 Working Days
Supplier	3GEN Export
