ER 88 TS TRANSFER SET

ER 88 TS Fuel Transfer Set

The ER 88 TS Fuel Transfer Set is a high-performance system designed for precise and efficient fuel transfer operations. Equipped with the ER 88 E meter and ER 1324 P fuel pump, this set delivers unmatched accuracy, reliability, and adaptability. Whether for industrial, agricultural, or transport needs, the ER 88 TS is an indispensable tool for managing liquid transfer with ease and precision.

Key Features of the ER 88 TS

• Integrated Meter and Pump System:
  • Meter: ER 88 E, ensuring precise measurements with electronic counter register functionality.
  • Pump: ER 1324 P vane-type pump, offering robust performance with a maximum flow rate of 240 liters per minute.
• Versatile Design:
  • Available with either an electronic or mechanical counter register.
  • Diesel or electric motor-driven options to suit diverse operational requirements.
  • Customizable for specialized applications such as cabinet-protected configurations or hose reel integration.
• Robust Construction:
  • Built with durable materials to ensure longevity and performance even in challenging environments.
  • Equipped with a water separator filter to maintain the purity of transferred fuel.

---

Technical Specifications

1. Meter:
   • Model: ER 88 E
   • Counter Register: Electronic (with optional mechanical counter register models available)
   • Maximum Accuracy: ±0.25%
2. Pump:
   • Model: ER 1324 P
   • Flow Rate: 240 lpm
   • Maximum Working Pressure: 6 bar (87 psi)
   • Viscosity: Up to 440 cP
   • Material Composition:
     • Pump Casing: Cast Iron (PIG GG 25)
     • Rotor: Sphero Casting (GGG 50)
     • Shaft: AISI 4140 Steel
     • Vane: FORTRON®
3. General Dimensions:
   • Compact frame with mobility-focused design for easy transport and installation.
   • Weight: Approximately 31 kg (pump) + motor and additional components.
4. Operational Highlights:
   • Fuel Types Supported: Diesel, biodiesel, leaded and unleaded gasoline, kerosene, jet fuel, vegetable oils, and more.
   • Working Temperature: -20°C to +60°C.
   • Power Options: Diesel or electric motor-driven configurations.

---

Applications and Benefits

The ER 88 TS Transfer Set is designed for seamless fuel management across a range of industries:

• Industrial Operations: Manage large-scale fuel transfer tasks with precision and reliability.
• Agricultural Use: Simplifies the transfer of diesel, biodiesel, and other fuels for farm equipment.
• Transport and Logistics: Efficiently refuels vehicles and machinery, reducing downtime.
• Construction: Ensures consistent fuel supply for heavy machinery on-site.
• Emergency Services: Portable and robust, ideal for fuel management in remote or urgent scenarios.

---

Compatibility with Other Transfer Set Models

The ER 88 TS is part of a versatile lineup of fuel transfer sets, each tailored to specific capacities and operational needs. Its unique configuration makes it compatible with:

• Meter-Based Sets:
  • ER 72 TS (700 lpm capacity, ER 1344 P pump)
  • ER 73 TS (700 lpm capacity, ER 1344 P pump)
  • ER 90 TS (100 lpm capacity, ER 1134 Y pump)
• Non-Meter Sets:
  • ER 1214 TS (400 lpm capacity, ER 1214 D pump)
  • ER 1324 TS (240 lpm capacity, ER 1324 P pump)

Customization Options

Tailor the ER 88 TS to your specific project or application. Options include:

• Cabinet-protected setups for harsh environments.
• Hose reel integration for easy fuel dispensing.
• Additional filtration systems for enhanced fuel purity.

---

Why Choose the ER 88 TS Fuel Transfer Set?

The ER 88 TS stands out with its reliable performance, adaptability, and ease of use. Designed for both standard and specialized applications, it ensures that your fuel transfer operations are efficient, safe, and cost-effective.

---
