ER 90 E FUEL COUNTER

ER 90 E Fuel Counter: Precision and Reliability in Fuel Measurement

The ER 90 E Fuel Counter is a state-of-the-art metering solution that delivers exceptional accuracy and reliability for various industrial and commercial fuel management applications. Designed with advanced positive displacement technology, this fuel counter ensures precise flow readings, even in challenging operating conditions. Its compact and robust construction, coupled with wide liquid compatibility, makes the ER 90 E a trusted choice for accurate fuel monitoring.

Key Features of the ER 90 E Fuel Counter

1. High Accuracy:
   • Achieves a precision level of ±0.25% across a range of pressure and flow rates.
   • Provides reliable performance for all compatible liquid types.
2. Innovative Design:
   • Features a 90° inlet and outlet connection with a 1” diameter, ideal for tight installation spaces.
   • Tri-piston positive displacement mechanism ensures consistent measurement accuracy.
3. Durable Materials:
   • Meter Casing: Cast iron (PIG GG 25) for long-term durability.
   • Air Separator Casing: Lightweight yet sturdy cast aluminum (AlSi10Mg).
   • Counter Register Screen: Polycarbonate glass ensures enhanced visibility and durability.
4. Optimized Performance Range:
   • Flow Rate: 10 liters per minute (lpm) to 100 lpm.
   • Pressure Range: Normal operating pressure of 3.5 bar (51 psi) and maximum pressure of 10 bar (145 psi).
   • Temperature Range: Efficient operation from -20°C to +40°C.
5. Multi-Liquid Compatibility:
   • Handles refined petroleum products, chemicals, and specialized liquids with ease.

Technical Specifications

Specification	Details
Flow Rate	10-100 lpm
Max Operating Pressure	10 bar (145 psi)
Temperature Range	-20°C to +40°C
Accuracy	±0.25%
Viscosity	Up to 440 cP
Meter Body Material	Cast Iron (PIG GG 25)
Air Separator Material	Cast Aluminum (AlSi10Mg)
Counter Register Screen	Polycarbonate Glass
Weight	39.5 kg
Dimensions (L x W x H)	31 × 57 × 60 cm
Flange Diameter	0.75” – 1”

Material Composition

• Meter Casing: Built from high-quality cast iron (PIG GG 25) for robust performance in demanding environments.
• Air Separator Casing: Made with cast aluminum (AlSi10Mg) for a lightweight yet durable build.
• Dynamic Seals and Gaskets: Constructed from FKM or Teflon materials to ensure reliability with high-petroleum products.

Applications of the ER 90 E Fuel Counter

The ER 90 E Fuel Counter is suitable for a wide range of industrial applications, thanks to its versatile design and robust construction. It is particularly useful for:

1. Refined Petroleum Products:
   • Effectively measures leaded and unleaded gasoline, diesel, biodiesel, and fuel oil.
   • Ideal for jet fuel, kerosene, lubricant oil, and vegetable oil.
2. Chemical Substances:
   • Efficiently handles adhesives, pesticides, nitrogen solutions, and solvents.
   • Suitable for measuring paints, inks, alcohols, and antifreeze liquids.
3. Specialized Liquids:
   • Accurately measures molasses, liquid sugar, vinegar, and frost-free liquids.
   • Capable of handling nitric and phosphoric acids, as well as fruit juices.

Compatible Models

The ER 90 E Fuel Counter integrates seamlessly with various fuel counter models, including:

• SP Series (Standard Petroleum): Designed for refined petroleum products like gasoline and diesel.
• AF Series (All Ferrous): Ideal for handling chemical substances such as adhesives and nitrogen solutions.
• SS Series (Stainless Steel): Optimized for specialized liquids and acidic substances like fruit juice and vinegar.

These compatible models ensure that the ER 90 E Fuel Counter meets diverse operational needs while delivering consistent and accurate results.

Why Choose the ER 90 E Fuel Counter?

1. High Precision: Provides exceptional accuracy in fuel flow measurement for critical applications.
2. Durable Build: Manufactured with premium materials for long-lasting reliability.
3. Wide Compatibility: Suitable for a broad range of liquids and compatible with multiple models.
4. Compact Design: Features a space-saving design that facilitates easy installation.
5. Trusted Performance: Proven to deliver consistent and dependable performance across industries.
