1824003, 1-824003 SCRAPER AMMANN

Overview

The 1-824003 Scraper Ammann is a heavy-duty, high-precision cleaning blade engineered to keep the drums of Ammann rollers and compactors perfectly clean during operation. Manufactured from wear-resistant alloy steel and protected by a durable powder-coat finish, it prevents soil, clay, or asphalt buildup that could otherwise compromise compaction quality. This essential component maintains surface contact uniformity, ensuring optimal vibration transfer and even layer density across every pass. At 3GEN Export, we provide the 1-824003 Scraper Ammann as an OEM-standard replacement compatible with a wide range of Ammann compaction machines. Each scraper undergoes precise machining and finishing to match Ammann’s design parameters, guaranteeing accurate fit, superior endurance, and smooth drum performance in challenging construction environments.

Function and Importance

During compaction, drums operate under continuous contact with soil or asphalt surfaces. Without a scraper, sticky materials accumulate on the drum, leading to vibration imbalance, reduced compaction efficiency, and surface irregularities. The 1-824003 Scraper Ammann eliminates this problem by continuously removing adhered material, thus maintaining consistent contact and rotational balance.

• Prevents material buildup on drum surfaces.
• Ensures uniform compaction force distribution.
• Reduces downtime for manual cleaning.
• Enhances drum longevity by minimizing abrasive wear.
• Improves operational efficiency and surface smoothness.

Design and Material Structure

The scraper’s structure combines industrial-grade steel strength with precision manufacturing for perfect alignment. Every 1-824003 Scraper Ammann is laser-cut, heat-treated, and coated to resist moisture, corrosion, and temperature fluctuations. The bright yellow powder finish improves visibility during maintenance, while the hardened edges guarantee consistent contact with the drum surface without damaging the steel cylinder.

• Material: High-tensile alloy steel, quenched and tempered for durability.
• Surface Protection: Industrial yellow powder-coat resistant to corrosion and abrasion.
• Mounting Precision: CNC-machined holes for perfect fit to OEM brackets.
• Edge Geometry: Optimized curvature for smooth scraping and minimal friction.

Technical Specifications

Part Number	1-824003
Alternative PN	1824003
Part Name	Scraper
Brand	Ammann
Application	Drum cleaning and compaction maintenance
Material	High-tensile alloy steel
Dimensions	1150 × 140 × 6 mm (approx.)
Weight	8.6 kg (≈ 18.9 lbs)
Finish	Powder-coated, corrosion-resistant yellow
Operating Temperature	−30 °C to +100 °C
Compatibility	Ammann drum rollers / compactors

Compatible Ammann Models

The 1-824003 Scraper Ammann fits a broad lineup of Ammann compaction equipment. Each machine benefits from improved cleanliness, vibration stability, and extended drum life. Compatible models include:

• Ammann ARX12 / ARX16 / ARX20 Tandem Rollers
• Ammann AV12 / AV16 / AV20 Articulated Rollers
• Ammann ARX23 / ARX26 / ARX40 Light Tandem Rollers
• Ammann ARP95 / ARP120 Pivot-Steer Rollers
• Ammann ASC70 / ASC90 / ASC110 Soil Compactors

For contractors operating mixed fleets, 3GEN Export can supply matched scraper sets for both front and rear drums, ensuring balanced cleaning and vibration performance across all Ammann rollers.

Installation and Maintenance

1. Clean the drum surface and mounting brackets before installation.
2. Align the scraper evenly along the drum curvature.
3. Tighten mounting bolts with calibrated torque wrenches.
4. Check clearance between the scraper edge and drum surface (typically 2–3 mm).
5. Inspect every 100 hours of operation for wear or edge damage.

Routine inspection is vital. Replace when thickness reduces by 25–30 % or if uneven wear appears. Proper maintenance prevents costly drum refinishing and ensures maximum machine uptime.

Performance Benefits

Superior Compaction Consistency

A clean drum provides steady vibration amplitude and homogeneous material density. The 1-824003 Scraper Ammann preserves uniform compaction quality across every meter of pavement or subgrade.

Reduced Maintenance Costs

Made from heat-treated steel, the scraper resists chipping and bending, minimizing replacement intervals and service downtime.

Operator Comfort and Machine Protection

By keeping drums balanced and free of sticky material, the scraper reduces vibration shocks transmitted to the operator and prevents excessive stress on bearings and hydraulic components.

Applications

• Highway and urban road construction
• Industrial and warehouse floor compaction
• Airport runway and taxiway projects
• Foundation base preparation for buildings
• Asphalt and soil compaction under wet conditions

Manufacturing Quality and Testing

All 1-824003 Scraper Ammann units supplied by 3GEN Export undergo ISO-certified inspection. Each production batch is checked for dimensional precision, hardness uniformity, and powder-coat adhesion. Hardness averages 45–50 HRC for balanced flexibility and wear resistance, while advanced anti-corrosive coating ensures performance in humid or dusty climates. Our OEM-standard partners employ robotic welding and CNC drilling for perfect repeatability, guaranteeing that every scraper fits directly into Ammann’s mounting system without modification.

Packaging and Global Delivery

Scraper blades are securely wrapped in protective film, labeled with product code and batch number, and boxed to avoid deformation during shipment. 3GEN Export provides worldwide logistics with express processing — most orders ship within 5 working days of confirmation. Our global supply chain ensures rapid delivery to Europe, the Middle East, Asia, Africa, and the Americas.

Why Choose 3GEN Export

• OEM-standard parts compatible with all Ammann rollers.
• Immediate availability and fast 5-day worldwide delivery.
• Strict quality control for durability and precision fit.
• Competitive pricing for both retail and bulk orders.
• Dedicated technical support for model verification and installation guidance.

As the global Marketplace of Heavy Machinery Spare Parts, 3GEN Export supplies construction companies, distributors, and equipment owners with high-grade Ammann components that enhance machine longevity and field performance.

Internal Links

Explore our complete selection of Ammann Spare Parts and Scraper Components for other compatible items.

Weight

8.6 kg (18.9 lbs)

Summary

The 1-824003 Scraper Ammann is a premium OEM-standard blade designed for long-lasting performance under demanding compaction conditions. Precision-engineered, corrosion-resistant, and perfectly balanced, it ensures a clean drum and consistent compaction results for Ammann rollers worldwide. Supplied by 3GEN Export — your trusted OEM supplier delivering globally in just 5 working days.

Manufactured in Turkey, these products are made using the latest technologies and built to meet the highest international standards. Each machine is a high-quality copy of the original, ensuring durability, precision, and performance that you can rely on for modern construction and metalworking projects.
