23B2711563 , 23B-27-11563 STUD BALL KOMATSU

Overview

The 23B-27-11563 STUD BALL KOMATSU is a precision-machined load-bearing component designed to deliver stability, flexibility, and durability to the boom and arm joints of Komatsu heavy machinery. By absorbing multidirectional loads and ensuring smooth pivot motion, this stud ball supports hydraulic articulation under the toughest excavation and mining conditions.

Developed with exact dimensional accuracy, the 23B2711563 STUD BALL KOMATSU helps maintain structural integrity and alignment in linkage assemblies. Manufactured from hardened alloy steel and polished to a mirror finish, it performs with maximum endurance under continuous vibration and impact.

As a trusted OEM-grade part, 3GEN Export supplies this stud ball to Komatsu users worldwide—offering reliable quality, strict tolerance control, and global delivery in only five working days.

Technical Description

The 23B-27-11563 STUD BALL KOMATSU functions as a spherical connection element linking the moving arms of the machine’s boom system. It allows for controlled motion while transmitting forces between structural components.

The upper section features a precision-formed spherical head, while the lower shank is cylindrical with an internally threaded bore. This configuration permits exact mounting with bolts or retaining pins, achieving both rotational and axial security inside the housing.

Each stud ball is CNC-machined to sub-millimeter precision and undergoes heat treatment to balance hardness with flexibility. The polished ball surface ensures reduced friction against the socket or bushing, minimizing wear and enhancing long-term reliability.

Material and Surface Characteristics

• Base Material: Hardened Cr-Mo alloy steel (42CrMo4)

• Surface Treatment: Mirror-polished + Zinc-phosphate anti-corrosion coating

• Hardness: 58 – 62 HRC outer surface / 35 HRC core toughness

• Lubrication Compatibility: Lithium, Calcium, or Graphite-based greases

• Thread Type: M16 × 1.5 internal thread (fine pitch)

• Tensile Strength: > 900 MPa

• Fatigue Limit: Over 10 million cycles

The combination of high-grade alloy and multi-phase tempering gives the 23B-27-11563 STUD BALL KOMATSUexceptional wear resistance, making it suitable for repetitive motion and shock exposure typical of excavator and loader applications.

Dimensional Specifications

(Dimensions may vary slightly within Komatsu tolerance range.)

Functional Role in Komatsu Machinery

Within Komatsu’s heavy-duty equipment, the 23B-27-11563 STUD BALL KOMATSU provides a flexible spherical joint between boom and linkage assemblies. Its role is to:

• Allow multi-axis movement without mechanical distortion

• Distribute stress evenly across pivot points

• Reduce vibration and fatigue in the arm assembly

• Maintain perfect alignment under hydraulic load

When used in excavators or wheel loaders, this stud ball’s polished geometry and load rating protect the surrounding bushings, sockets, and seals from uneven wear—ensuring extended operational uptime.

Engineering Highlights

1. Spherical Accuracy

CNC machining guarantees consistent radius curvature and concentricity. The precision profile keeps rotational torque uniform, preventing uneven pressure and joint noise.

2. Thermal Hardening Technology

Through controlled induction hardening and tempering, the component reaches surface hardness of 58–62 HRC, providing resistance against abrasive dust and hydraulic shock.

3. Internal Thread Mounting

Unlike externally threaded designs, the internal thread of the 23B-27-11563 STUD BALL KOMATSU ensures cleaner aesthetics, easier torque application, and enhanced tensile strength during installation.

4. Corrosion Resistance

A two-layer coating—zinc phosphate primer and sealing film—protects against rust even after thousands of operating hours in humid environments.

5. Mirror Finish Surface

Surface roughness (Ra < 0.05 µm) ensures minimal friction, improving efficiency and lowering energy loss in hydraulic systems.

Compatible Komatsu Models

The 23B-27-11563 STUD BALL KOMATSU is fully compatible with the following equipment:

• Komatsu PC200-7 / PC200-8

• Komatsu PC220-7 / PC220-8

• Komatsu PC240LC-8

• Komatsu PC270 and PC300 Series

• Komatsu WA320 / WA380 Wheel Loaders

• Komatsu D85EX-15 Dozers

• Komatsu GD675 Grader Assemblies

This part integrates seamlessly with factory linkages without modification, maintaining OEM-level fitment and mechanical alignment.

Installation Guidelines

Step 1 — Inspection and Preparation

Clean all socket bores and bushings. Remove debris and check for wear or distortion.

Step 2 — Alignment

Position the stud ball so that the spherical head sits evenly within the bore. Ensure no gap exists between the flange and mounting surface.

Step 3 — Fastening

Use a torque-calibrated wrench to tighten the bolt to the specified torque (typically 190 – 210 Nm). Avoid over-torquing.

Step 4 — Lubrication

Apply a thin layer of high-pressure grease on the ball surface before final assembly. Re-lubricate at regular intervals.

Step 5 — Functional Check

After installation, move the joint through its full range to confirm smooth motion and proper alignment.

Advantages of Using 23B-27-11563 STUD BALL KOMATSU

• High Structural Integrity: Supports extreme mechanical loads without deformation.

• Extended Component Life: Reduces wear on bushings and pins.

• Low Friction: Polished geometry ensures silent operation.

• Corrosion-Proof: Protected against oxidation and humidity.

• Plug-and-Play Compatibility: No modifications required for Komatsu equipment.

• Quick Global Delivery: Available worldwide within five working days from 3GEN Export.

Typical Applications

The 23B-27-11563 STUD BALL KOMATSU is engineered for applications requiring a high-load pivot:

• Excavator boom and stick assemblies

• Loader link arms and bell cranks

• Bulldozer tilt and lift mechanisms

• Articulated joint systems in graders and scrapers

• Heavy-duty mining and quarry machinery

Its robust design ensures safe, continuous operation even in harsh climates and dust-laden construction sites.

Maintenance and Care

• Re-grease every 250 hours of operation.

• Check for surface pitting or metal fatigue signs during routine service.

• Replace immediately if play exceeds manufacturer tolerance (> 0.5 mm).

• Store in a dry, sealed environment when not installed.

By maintaining the 23B-27-11563 STUD BALL KOMATSU under recommended conditions, operators can extend service life by up to 40 %.

Quality Assurance

Every unit supplied by 3GEN Export is individually verified through a rigorous inspection process:

1. Dimensional Verification: CMM scanning within ± 0.01 mm tolerance.

2. Material Certification: Heat-number traceability and chemical composition analysis.

3. Hardness Testing: Rockwell HRC tests on each production batch.

4. Dynamic Load Testing: Simulated 7 ton cyclic load for 50 hours.

5. Surface Inspection: Ra measurement and visual check for micro-scratches.

Only stud balls passing these standards receive the 3GEN Export quality seal before dispatch.

Why Choose 3GEN Export

3GEN Export is a recognized OEM supplier and global marketplace for heavy machinery spare parts. Our mission is to keep Komatsu machines running at peak efficiency through reliable parts and express logistics.

• Worldwide Coverage: Delivery to over 100 countries in 5 working days.

• OEM Fit Guarantee: All parts meet manufacturer mounting standards.

• Comprehensive Portfolio: Serving Komatsu, Caterpillar, Hitachi, Volvo, and more.

• Secure Transactions: Encrypted payment and traceable shipping.

• Technical Support: Specialist engineers assist in part selection and installation.

Choosing 3GEN Export means choosing durability, precision, and trust.

Technical Summary

Packaging and Logistics

Every 23B-27-11563 STUD BALL KOMATSU is vacuum-sealed in anti-rust film, then boxed in reinforced corrugated cartons with individual barcode labels. Bulk shipments are palletized and heat-treated to meet international export regulations.

Documents included per shipment:

• Inspection certificate and MTR (Material Test Report)

• Packing list and invoice

• Warranty card (12 months coverage)

With hubs in Türkiye, Germany, and the UAE, 3GEN Export ensures fast dispatch and customs-ready paperwork for clients worldwide.

Environmental Compliance

The 23B-27-11563 STUD BALL KOMATSU complies with:

• ISO 9001:2015 (Quality Management)

• ISO 14001:2018 (Environmental Management)

• RoHS / REACH chemical safety directives

• EU Machinery Directive 2006/42/EC

No hazardous substances are used during manufacturing or coating.

Long-Term Performance

When installed and maintained correctly, this stud ball can achieve a lifespan of over 15,000 operating hours. The optimized surface geometry prevents fretting corrosion and micro-pitting, ensuring the boom assembly retains its factory precision for years.

The 23B-27-11563 STUD BALL KOMATSU is not just a spare part—it is a performance component built for machines that define productivity in construction and mining operations.

Conclusion

The 23B-27-11563 STUD BALL KOMATSU (23B2711563) is an essential mechanical joint for Komatsu excavators, dozers, and loaders, providing the perfect blend of strength, flexibility, and precision. Engineered from hardened alloy steel and finished to OEM-grade tolerances, it delivers reliable pivot movement under extreme operating conditions.

Supplied by 3GEN Export, your trusted OEM supplier of Komatsu spare parts with worldwide delivery in just five working days, this component ensures your machine keeps working as hard as you do.

Manufactured in Turkey, these products are made using the latest technologies and built to meet the highest international standards. Each machine is a high-quality copy of the original, ensuring durability, precision, and performance that you can rely on for modern construction and metalworking projects.
