80760 BUSHING VOLVO – Heavy-Duty Transmission Bushing for Volvo Motor Graders

Overview of the 80760 Bushing

The 80760 BUSHING VOLVO is a heavy-duty transmission component designed for the demanding working conditions of Volvo motor graders. Installed in critical pivot and support points in the drivetrain or articulation assemblies, this bushing helps keep the machine stable while transmitting motion smoothly between moving parts.

In daily grading work, the front frame, tandem drive and articulation points are exposed to high loads, vibration and continuous micro-movements. The 80760 BUSHING VOLVO is engineered to absorb these forces, reduce metal-to-metal contact, and extend the life of shafts, pins and housings. When this small part is correctly selected and replaced on time, it directly contributes to smoother steering response, accurate blade control and lower long-term maintenance costs.

At 3GEN Export, we supply OEM-standard bushings like the 80760 reference for customers operating Volvo Motor Graders around the world. Our focus is to deliver reliable parts that match the dimensions, tolerances and material quality your machine was designed for, so you can get back to work with minimum downtime. 3GEN Export+1

Function of the 80760 Bushing in Volvo Motor Graders

Load support and alignment

Inside the grader’s drivetrain and articulation systems, each shaft and pin needs a stable sliding surface. The 80760 BUSHING VOLVO provides this surface, centering the rotating component and distributing radial loads over a wider area. This reduces point pressure, keeps the pin aligned, and helps the surrounding housing stay dimensionally stable over thousands of operating hours.

In applications such as steering knuckles, front frame pivots or tandem drive linkages, the bushing works as a sacrificial wear element. Instead of allowing the machine’s main structural components to wear, the bushing takes the friction and can be renewed during scheduled maintenance.

Vibration damping and smoother operation

Grading roads, shaping surfaces and working on uneven terrain produces continuous shock and vibration. The 80760 BUSHING VOLVO acts as a buffer between metal components. Its material and surface finish are chosen to:

• Minimize vibration transmitted to the frame

• Reduce noise and harshness felt by the operator

• Protect neighbouring parts such as seals and bearings

By damping these impulses, the bushing contributes to a more stable moldboard, more consistent blade angle, and more precise finishing on gravel or soil.

Protection against wear and corrosion

In real-world conditions, Volvo motor graders work in dust, mud, moisture and sometimes corrosive environments. The 80760 BUSHING VOLVO is designed as a replaceable wear part that protects pins and bores from abrasive particles and rust.

With correct lubrication and periodic inspection, this bushing helps:

• Prevent ovalization of housings

• Reduce scoring and fretting on pins

• Keep clearances within design limits for longer

When wear exceeds allowable tolerances, the bushing can be pressed out and replaced, restoring tightness and mechanical accuracy without major structural repairs.

Technical Specifications of 80760 Bushing

Core dimensions and material concept

While exact nominal dimensions depend on the specific grader configuration and housing design, the 80760 BUSHING VOLVO is typically produced as a cylindrical, heavy-wall bushing suitable for high-load transmission and articulation positions. Key engineering characteristics include:

• High-strength steel or equivalent alloy body

• Precision-machined inner and outer diameters

• Accurate roundness and cylindricity for even load distribution

• Surface finish optimized for lubrication film retention

• Optional surface treatment (such as coating or plating) for enhanced corrosion resistance

These features ensure stable performance under the shock loads and reversing motion characteristic of Volvo Motor Graders.

Weight of the 80760 Bushing

For spare-parts planning and freight calculation, the approximate weight of the 80760 reference is:

• Approximate weight: 0.52 kg 3GEN Export+1

This low individual weight makes the bushing easy to handle and economical to ship, yet its compact mass is sufficient to withstand significant mechanical loads.

Typical Applications and Compatible Volvo Equipment

According to aftermarket parts listings and product catalogs, the 80760 BUSHING VOLVO is associated with the Volvo Motor Grader range and is used in the transmission and articulation systems of these machines. 3GEN Export

In practice, this bushing is commonly specified for:

• Volvo Motor Graders operating in road building and maintenance

• Machines working in quarry and mining support tasks

• Graders used in infrastructure, airport and industrial platform construction

Because grader configurations and serial ranges vary, exact model compatibility should always be confirmed via the machine’s parts catalog or serial-number-based lookup. Customers typically find this reference within the Volvo Motor Grader parts group, especially in assemblies related to:

• Transmission and driveline supports

• Articulation pivots

• Tandem drive or axle linkages

If you share your machine’s VIN or serial number with 3GEN Export, our technical team can match the 80760 reference to your specific grader configuration and confirm whether this bushing is correct for your application.

Key Advantages of Using a Correct 80760 Bushing

1. Improved component life and reduced repair costs

Installing a high-quality 80760 BUSHING VOLVO prevents premature wear on expensive components such as:

• Pins and shafts in the transmission area

• Machined bores in housings and frames

• Tandem box or axle structures

Since the bushing is the first part to wear, timely replacement preserves the integrity of the surrounding parts. This lowers the risk of oversized bores, cracked housings or misaligned driveline components, which are far more costly to repair.

2. Better grader stability and grading accuracy

A worn or loose bushing in a Volvo Motor Grader can lead to:

• Excessive play in the articulation or tandem system

• Blade chatter and inconsistent cutting depth

• Steering instability and poor operator confidence

By renewing the 80760 BUSHING VOLVO at the recommended interval, you recover the designed stiffness and alignment of the linkage. This results in:

• More precise moldboard control

• Smoother passes on gravel and compacted layers

• Higher productivity with fewer re-works

3. Reduced vibration, noise and operator fatigue

Graders are often used for long shifts on rough surfaces. Excessive play and vibration from worn bushings make the operator’s job harder and can accelerate wear in other parts. With a fresh 80760 bushing installed, the machine feels tighter, quieter and more controlled. Over time, this improves operator comfort and helps keep sensitive components — such as hydraulic valves and electronic sensors — under less mechanical stress.

Installation and Maintenance Best Practices

Preparing for replacement

Before replacing the 80760 BUSHING VOLVO, follow these basic steps:

• Check the service manual and parts catalog for your exact machine and confirm the bushing’s position and quantity.

• Park the grader on level ground, secure it and relieve hydraulic and mechanical loads in the area where you are working.

• Inspect pins, shafts and housings for visible damage; if these parts are worn beyond limit, plan to renew them together with the bushing.

Removing the worn bushing

Use the correct pullers or press tools recommended for your grader type. Avoid improvising with chisels or hammers that could damage the bore. Typical procedure includes:

• Cleaning the area and removing dirt, rust and old grease

• Using a hydraulic or mechanical press to push the worn bushing out of its housing

• Measuring the bore after removal to ensure it is still within tolerance

If the bore has become oval or oversized, it may need repair before installing a new 80760 bushing.

Installing the new 80760 bushing

For proper installation of a new 80760 BUSHING VOLVO:

• Lightly lubricate the outer surface and the bore to ease pressing and avoid scoring

• Align the bushing with the bore and press it in slowly and evenly, keeping it square at all times

• Ensure any lubrication grooves or holes are oriented as specified in the service documentation

• After installation, check that the pin or shaft rotates smoothly with the correct running clearance

Finally, apply fresh grease or lubricant according to the grader’s lubrication schedule, and bleed any trapped air in lubrication lines.

Ongoing inspection and service

Even a robust bushing such as the 80760 reference requires periodic checks. Include this component in your preventive maintenance plan by:

• Inspecting for play or noise during visual and functional checks

• Monitoring the condition of grease (contamination or metal particles)

• Renewing seals and cleaning lubrication points in the same area

A disciplined approach to maintenance keeps the 80760 BUSHING VOLVO performing for long intervals and helps avoid unscheduled downtime.

Why Source the 80760 Bushing from 3GEN Export?

3GEN Export is a dedicated OEM-standard supplier for heavy machinery spare parts, including bushings, pins and driveline components for Volvo Motor Graders. 3GEN Export+1

When you order the 80760 bushing from us, you benefit from:

• OEM-level quality: Parts manufactured to tight tolerances, with reliable materials and heat treatment suitable for high-load grader applications.

• Specialization in heavy equipment: Focus on construction and road-building machines, particularly graders, excavators, loaders and drilling equipment.

• Global shipping performance: We ship worldwide and typically deliver within 5 working days, helping you minimize machine downtime and project delays.

• Technical support: Our team helps you cross-reference part numbers, verify compatibility using machine serial numbers and select related components in the same assembly.

Whether you operate a single grader or a large road-building fleet, partnering with 3GEN Export for the 80760 BUSHING VOLVO simplifies your procurement process and ensures consistent quality across your machines.

Summary

The 80760 BUSHING VOLVO is a compact but critical transmission and articulation component used on Volvo Motor Graders. It supports shafts and pins, reduces friction and vibration, and protects expensive structural parts from premature wear. With the correct 80760 reference installed and maintained, your grader delivers smoother operation, better grading accuracy and lower lifecycle costs.

By sourcing this bushing from 3GEN Export, you gain access to OEM-standard quality, expert technical support and fast worldwide delivery in 5 working days, so your machine can return to productive work as quickly as possible.
